Mechanical mounting
Do not intentionally close it. Also it is necessary to make a drain for water
at the bottom of the niche which will serve to divert water out.
It is also necessary to provide supply of a power cable, additional modules
and the local network.
Before installation of the outdoor panel it is necessary to provide a hole
or a recess into a wall with dimensions 144×360x59 mm (for flush mount)
dimensions of the bracket (mounting box) = 142×358×58 mm.
Attention: the hole at the bottom is designed to drain the water.
142 mm
358 mm
239 mm
EAN: 5060514912829 (BLACK)
EAN: 5060514912843 (GOLD)
EAN: 5060514912836 (SILVER)
Outdoor Panel
Flush Bracket
Niche Screws Outdoor Panel
144
mm
360
mm
10
9
-
1
30
cm
161 mm
382 mm
49 mm
1
2
3
4 5 6
7 8 9
0
x
i
1
2
3
4
5
6
7
8
9
0
x
i
