The Basalte Eve Plus is a sophisticated docking system designed for various iPad models, allowing them to be securely mounted and charged on walls or tables. This system comprises several components, including the Eve Plus sleeve, a cover, a softy grip, a Plus connector, screws, and a USB-C connector. The Eve Plus system is available in different variants to accommodate specific iPad models:

Eve Plus Mini (0124-xx)

Dimensions: 213.80 mm (8.79") x 138.80 mm (5.47")
Compatibility: iPad Mini (6th generation)

Eve Plus Air (0123-xx)

Dimensions: 266 mm (10.47") x 182.5 mm (7.19")
Compatibility: iPad Pro 11" (1st, 2nd, 3rd generation), iPad Air 10.9" (4th, 5th generation)

Eve Plus (0125-xx)

Dimensions: 267 mm (10.51") x 183.5 mm (7.27")
Compatibility: iPad 10.9" (10th generation)

Function Description

The primary function of the Eve Plus is to provide a secure and aesthetically pleasing way to integrate an iPad into a smart home or office environment. It allows the iPad to be docked either horizontally (landscape) or vertically (portrait) while ensuring it remains charged through the Plus connector. The system is compatible with Basalte's Eve Plus wall base (0130-xx) and table base (0150-xx), offering versatile mounting options.

Installation and Usage

Mounting the iPad:

Preparation: Begin by unmounting the screws on the back of the Eve Plus sleeve and sliding off the cover.
Placement: Place the Eve Plus sleeve on a flat surface with the softy grip facing downwards.
iPad Insertion: Gently slide the iPad into the sleeve. It is crucial to avoid applying excessive force and to ensure the iPad remains aligned with the sleeve throughout the process. The iPad should sit flush with the frame once fully inserted.
Connector Engagement: Gently slide the USB-C connector into the iPad's port.
Securing the Cover: Gently reattach the cover by sliding it back into its original position.
Final Lock: Lock the cover in place using the screws.

Important Installation Note: It is essential to follow these steps in the correct order, as an incorrect installation procedure can potentially damage the frame of the device.

Removing the iPad:

Unscrewing the Cover: Remove the screws that hold the cover in place and slide the cover off the frame.
Positioning the Sleeve: Place the Eve Plus sleeve on a flat surface with the softy grips facing downwards.
iPad Removal: Gently slide the iPad out of the sleeve, maintaining alignment with the sleeve. Avoid applying excessive force or pulling the iPad up or down during removal. Ensure the iPad remains flush with the sleeve until it is completely removed.

Important Technical Specifications and Features

Docking Versatility: Supports both horizontal (landscape) and vertical (portrait) docking orientations.
Charging Capability: Keeps the iPad charged while docked via the Plus connector.
Compatibility with Basalte Bases: Designed to work seamlessly with Eve Plus wall bases (0130-xx) and table bases (0150-xx).
Material and Design: The system emphasizes a sleek design, ensuring the iPad sits flush within the frame. The softy grip helps secure the iPad and protects it from scratches.

Important Remarks and Limitations

USB-C Connector Compatibility: Eve Plus sleeves equipped with USB-C connectors are not compatible with Eve Plus wall base USB (0130-02) and Gigabit POE adapter (0610-20). This is a critical point for users to consider when selecting accessories.
Always-on Display: The Eve Plus system does not support always-on display configuration for the iPad. Users should be aware of this limitation if their workflow relies on this feature.

Maintenance Features

The design of the Eve Plus focuses on ease of installation and removal, which inherently contributes to its maintainability. The use of screws for securing the cover allows for straightforward access to the iPad for cleaning or replacement. The robust construction is designed to protect the iPad while docked.

Manufacturing and Branding

Made in Belgium: The Basalte Eve Plus is manufactured in Belgium, indicating a commitment to quality and craftsmanship.
Trademarks:
- Basalte is a registered trademark of Basalte bv.
- EVE Plus is a registered trademark of Basalte bv.
- EVE Plus is a registered design of Basalte bv.
- iPad is a registered trademark of Apple Inc.

Contact Information

Basalte bv Fraterstraat 37b | 9820 Merelbeke | Belgium Tel: +32 9 385 78 38 Email: info@basalte.be Website: www.basalte.be
