SaniDry CX INSTALLER'S AND OWNER'S MANUAL
7
SaniDry CX Installer’s & Owner’s Manual
SaniDry CX SERVICE PARTS LIST • To order, contact your local Basement Systems Dealer
12 TROUBLESHOOTING
“Fan only runs when dehumidifier is on” mode:
Blower and compressor do not run.
1. Unit unplugged or no power to outlet, circuit
breaker tripped
2. Humidity control set too high
3. Loose connection in internal wiring
4. Humidity control is defective
4.a. The unit will continue to run at a default setting
of 50% RH.
5. Humidity sensor defective or not connected
properly.
5.a. The unit will continue to run and will perform a
defrost cycle as required.
In either mode:“Fan runs all the time” or
“Fan only runs when dehumidifier is on” with
“Humidity Control” turned to ON, blower runs but
compressor does not.
1. In a defrost cycle, ambient temperature too low
2. Loose connection in compressor circuit
3. Defective compressor overload
4. Defective compressor or compressor
run capacitor
“Fan runs all the time”mode: Blower runs but
compressor cycles on & off.
1. Low ambient temperature and/or humidity causing
unit to cycle through defrost mode
2. Cold coil sensor is defective or loose. The unit will
continue to run and will perform a defrost cycle
every 53 minutes of operation.
3. Defective compressor overload
4. Defective compressor
5. Low refrigerant charge
In either mode:“Fan runs all the time” or “Fan
only runs when dehumidifier is on”: Blower does
not run but compressor runs briefly but cycles on
and off.
1. Loose connection in blower circuit
2. Obstruction preventing blower impeller rotation
3. Defective blower
4. Defective mode switch
Evaporator coil frosted continuously, low
dehumidifying capacity.
1. Dirty air filter or air flow restricted
2. Cold coil sensor is defective or loose. The unit will
continue to run and will perform a defrost cycle
every 53 minutes of operation.
3. Low refrigerant charge
Warm air discharging from unit.
This is normal while dehumidifying.
If none of the above has fixed the issue, call the
service department at 1-800-640-1500
Replacement Parts -For more information on the
SaniDry CX, call 1-800-640-1500
# Accessory Name QTY(PC) Specifications/Material
1 Pre-filter 1 Aluminum,mesh,foam
2 Main air filter 1 MERV-11-1”thick
3 Humidity control switch knob 1 ABS
4 Fan control switch knob 1 ABS
5 Control panel label 1 PVC
6 Cover 1 LLDPE
7 Line cord 1 105℃ 300V 16AWG*3,125V 13A
8 control box cover 1 Galvanized steel sheet
9 PCB control system 1 115V/60Hz
10 Fan control switch 1 250V/25A
11 Potentiometer 1 0-2.2KΩ，4W
12 Potentiometer bracket 1 Galvanized steel sheet
13 Compressor capacitor 1 35μF/250V
14 Control box bracket 1 Galvanized steel sheet
15 Wire guard grommet 4 Rubber
16 Control box 1 Galvanized steel sheet
17 Fan guide 1 Steel sheet Spray plastics
18 Fan 1 Aluminum alloy
19 Fan guard 1 Steel
20 Fan housing 1 Steel sheet Spray plastics
21 Anti-vibration gasket 1 Rubber
22 Fan capacitor 1 12.5μF/250V
23 Fan motor 1 115V/60HZ
24 Cable clamp 1 Flame-resisting ABS
25 Level 1
26 Compressor rubber grommet 3 Rubber
27
Compressor rubber grommet bolt sleeve
3 Steel
28 Compressor 1 5RS072UBA21 115V/60Hz R410A
29 Over-load protector 1 B290-150-241H
30 Gasket terminal cover 1 EPT
31 Terminal cover 1 EPT
32 Terminal cover gasket 1 EPT
33 Nut-terminal cover 1 M5-Steel
34 Condenser 1 Al,Cu and steel
35 Condenser cover 1 Galvanized steel sheet
36 Rating label 1 Polyester adhesive
37 Heat exchanger 1 PP
38 Humidity sensor 1
39 Left bracket 1 Galvanized steel sheet
40 Right bracket 1 Galvanized steel sheet
41 Evaporator 1 Al,Cu and steel
42 Water tray 1 Stainless steel
43 Defrost temperature sensor 1
44 Air flow guide part I 1 Galvanized steel sheet
45 Air flow guide part II 1 ABS
46 Air flow guide part III 1 ABS
47 Capillary tube 2 2.5*1.0
48 Suction tube 1 9.52*0.8 Copper Tube
49 Fill Valve 1
50 Insulation 1 PE
51 Condenser tube 2 9.52*0.8 Copper Tube
52 Filter/dryer 1
53 Process tube 1 6.35*0.8 Copper Tube
54 Discharge tube 1 6.35*0.8 Copper Tube
55 Drain fitting I 1 Nylon
56 Drain fitting II 1 Nylon
57 Base 1 LLDPE
58 Drain plug 2 Rubber
59 Leveling feet 4 Rubber/steel
