Rated conditions for the activation/sensitivity/response delay (response time)
and performance in case of fire
Fulfilled
Operational reliability Fulfilled
Tolerance for voltage output Fulfilled
Durability of operational reliability and response delay Fulfilled
Durability of operational reliability. resistance to vibration Fulfilled
Durability of operational reliability, resistance to humidity Fulfilled
Durability of operational reliability, resistance to corrosion Fulfilled
Durability of operational reliability, electrical stability Fulfilled
The declaration of performance with the number 1369245 can be viewed here:
www.conrad.com/downloads.
Intended use
The smoke detector uses the scattered light principle and already detects the smallest amounts
of smoke particles penetrating its housing. Installation and operation must be carried out in dry
and dust-free interiors, where under normal use no steam or smoke development occurs (e.g.
kitchens, open fires).
The smoke detector is used for the early detection of smoke formation in private living rooms
and bedrooms, and as soon as smoke is detected it emits a loud alert to warn the residents
early on.
The smoke detector is operated with a 9 V block battery.
The safety instructions have to be followed without fail! Please read the operating instructions
carefully and do not discard them. If you pass the product on to a third party, please hand over
these operating instructions as well.
Any use other than that described above will lead to damage to the product and will expose
you to additional risks, such as short-circuiting, fire, etc. No part of the product may be modified
or converted!
This product complies with the applicable national and European requirements. All names
of companies and products are the trademarks of the respective owners. All rights reserved.
Package contents
• Smoke detector
• 1x 9 V block battery
• Installation material (2x screws, 2x wall screw-plugs)
• Operating instructions
Explanation of symbols
This symbol points to specific risks associated with handling, function or operation.
The “arrow” symbol points to special tips and operating information.
Observe the operating instructions!
Safety instructions
Damage due to failure to follow these operating instructions will void the
warranty! We do not assume any liability for any resulting damage!
We do not assume any liability for material and personal damage caused by
improper use or non-compliance with the safety instructions! In such cases,
the warranty will be null and void!
• Theunauthorisedconversionand/ormodicationoftheproductisnotpermitted
for safety and approval reasons (CE).
• The product is not a toy and should be kept out of the reach of children!
• The product must not get damp or wet!
• Do not stick anything over the product (e.g. wallpaper); do not varnish/paint!
• Do not use the product in rooms with adverse environmental conditions, where
combustible gases, vapours or dust are or may be present! There is a risk of
explosion!
• The product must not be exposed to extreme temperatures, strong vibrations or
heavy mechanical stress.
• Do not carelessly leave the packaging material lying around since this may be-
come a dangerous plaything for children.
• Handle the product with care; it can be damaged by impacts, blows, or accidental
falls, even from a low height.
Battery information
Do not put rechargeable batteries into the smoke detector.
Use only a non-rechargeable battery to ensure a safe and the longest possible op-
eration.
• Batteries should be kept out of the reach of children.
• Do not leave batteries lying around in the open; there is a risk they may be swallowed by
children or pets. If they are swallowed, consult a doctor immediately.
• Leaking or damaged batteries can lead to caustic burning of the skin. Therefore, use suitable
protective gloves.
• Batteriesmustnotbeshort-circuited,openedorthrownintoare.Thereisariskofexplosion!
• Do not recharge conventional non-rechargeable batteries; risk of explosion!
• Please pay attention to the correct polarity (plus/+ and minus/-) when inserting the battery.
Selecting the installation location
General information
A fire is not necessarily dangerous because of the flame, but due to the toxic smoke produced
during combustion. A few breaths, especially while asleep, can already lead to unconscious-
ness. This is why the site of the installation must be chosen carefully.
Recommended installation sites for smoke detectors
• Install smoke detectors in close proximity of the bedrooms. Also plan for escape routes from
bedrooms; those rooms are usually the farthest from the exit. If there is more than one bed-
room, install additionally a smoke detector in every bedroom.
This also extends to other rooms providing sleeping facilities (such as children’s room, guest
room, etc.).
• Install smoke detectors in order to safeguard stairways; stairways act easily like chimneys for
smokeandre,andmaycontributetofurtherrespread.
• Makesuretoinstallatleastonesmokedetectoroneachoor.
• Install a smoke detector in every room where electrical appliances are present (e.g.TV in the
living room). Often those devices in particular pose a risk of heavy, toxic smoke formation.
• It is recommended to install more than one smoke detector, if the rooms are larger.
Bedroom
Kitchen
Bedroom
Bedroom
Staircase
Staircase
Hallway Bedroom
Living room
Bedroom
Bath
-
room
Living room
Heat, smoke, fire
Ceiling
Ideal site to install
Individual storey
Smoke detector for minimum protection
Smoke detector for maximum protection
Building with several floors
Corner
(dead space, never!)
60 cm
Operating instructions
Smoke detector “KD-133A”
Item no. 1369245
Version 08/16
°
16
1134
DOP NO.: 1369245
EN 14604:2005/AC:2008
SMOKE ALARM
KD-133A
