C
hain should be loose enough to To adjust the drive chain, loosen
move ½”-3/4” when pressed with the four bolts holding the motor
one
finger. adjuster plate to the gear box.
N
ote: (Do not over tighten chain.) Adjust the chain tension with the
This will damage the hydraulic adjuster bolt welded to the end of
motor shaft seal. the adjuster plate.
(Front and back)
ADJUST
GREASE
GREASE
