INSTALLATION GUIDE
*For assemblies including ange nuts (intergrated washer nuts), you will not have at washers in your kit.
12
ASSEMBLE THE MAIN POLE
HOLDER TO THE PIVOT
Assemble the main pole holder (B)
to the pivot using 1 bolt (J),
1 at washer (L) and 1 nut (K)
installed in the center hole.
12.1 12.2
Tighten rmly.
12.3 12.4
13
LEVEL THE MAIN POLE HOLDER
Level the main pole holder (B)
crosswise and lenghtwise.
13.1 13.2
