1-10 BE1-50/51B General Information 9252000991 Rev N
Impulse
Qualified to IEC 255-5.
Radio Frequency Interference (RFI)
Field-tested using a 5-watt, hand-held transceiver operating at random frequencies centered around 144
MHz and 440 MHz, with the antenna located 6 inches from the relay in both horizontal and vertical
planes.
Vibration
Withstands 2 G in each of three mutually perpendicular planes swept over the range of 10 to 500 Hz for a
total of 6 sweeps, 15 minutes each sweep.
Shock
Withstands 15 G in each of three mutually perpendicular planes.
Environment
Operating Temperature: –40°C to 70°C (–40°F to158°F)
Storage Temperature: –50°C to 70°C (–58°F to 158°F).
Agency Recognition
UL Recognized/CSA Certified
UL Recognized per Standard 508, UL File No. E97033. CSA Certified per Standard CAN/CSA-C22.2 No.
14-M91, CSA File No. LR 23131.
Note: Output contacts are not UL Recognized/CSA Certified for voltages greater than 250 volts.
GOST-R Certification
GOST-R certified No. POCC US.ME05.B03391; complies with the relevant standards of Gosstandart of
Russia. Issued by accredited certification body POCC RU.0001.11ME05.
Patent
Patented in U.S., 1998, U.S. Patent No. 5751532.
Physical
Weight: 8.6 lb (3.9 kg)
