Basler BE1-700C User Manual

BE1-700C
Digital Overcurrent
Protective Relay
OPTION 1
N) No reclosing
R) Reclosing
CASE
X) Panel mount
non-drawout case
OPTION 2
N) No Option
BE1-700
X
N
POWER SUPPLY
And
CONTACT RANGE
1) 48 VDC
2) 120 VAC/125 VDC
3) 24 VDC
4) 240 VAC/250 VDC
COMMUNICATIONS
PROTOCOLS
0) RS-485 ASCII Protocol,
No Ethernet Protocol
1) RS-485
Modbus
™
Protocol,
No Ethernet Protocol
4) RS-485 ASCII
Protocol, BESTNet
Ethernet Protocol
5) RS-485 Modbus
Protocol, BESTNet
Ethernet Protocol
7) RS-485 ASCII Protocol,
Modbus/TCP Ethernet
Protocol
SELECTING COMMUNICATIONS PROTOCOL
All units include two independent communications ports
standard: Com0 (front RS-232) and Com2 (rear RS-485).
ASCII Communications is standard on Com0 and Com2.
Com0 is always ASCII.
• If BESTNet is ordered (option 4 or 5), an Ethernet Port
(Com1) is added with ASCII and Web Protocols only. Com2
is ASCII or Modbus, depending on ordering option.
• If Modbus/TCP is ordered (option 7), Ethernet Port Com1
is added with Modbus/TCP only. No web or email features
are added, and BESTCOMS™ cannot be used over Com1.
Com2 can be used for ASCII and BESTCOMS™. ASCII
Communications is standard on Com0 and Com2.
APPLICATIONS
FEATURES
FUNCTIONAL DESCRIPTION
BESTlogic
SPECIFICATIONS
ORDERING INFORMATION
SAMPLE STYLE NUMBER
The style number identification chart below defines the electrical characteristics and
operation features included in the BE1-700C relay. For example, if the style number
were BE1-700 F0R4X5N, the device would have the following:
BE1-700 Digital Overcurrent Protective Relay
(F0) - 5 Amp Nominal Phase Current with 1 Amp Nominal Ground Input
(R) - Reclosing
(4) - 240 VAC/250 VDC Power Supply, 240 VAC/250 VDC Contact Inputs
(X) - Panel mount, non-drawout case
(5) - Modbus on RS-485 port, BESTNet Ethernet protocol
(N) - Not applicable
INPUT SENSING
B0) 1 Amp Nominal
Phase Current,
1 Amp Nominal
Ground
E0) 5 Amp Nominal
Phase Current,
5 Amp Nominal
Ground
F0) 5 Amp Nominal
Phase Current,
1 Amp Nominal
Ground
Route 143, Box 269, Highland, Illinois U.S.A. 62249
Tel +1 618.654.2341 Fax +1 618.654.2351
e-mail: info@basler.com
P.A.E. Les Pins, 67319 Wasselonne Cedex FRANCE
Tel +33 3.88.87.1010 Fax +33 3.88.87.0808
e-mail: beifrance@basler.com
1300 North Zhongshan Road, Wujiang Economic Development Zone
Suzhou, Jiangsu Province, PRC 215200
Tel +86(0)512 6346 1730 Fax +86(0)512 6346 1760
e-mail: beichina@basler.com
