Publication
9318100995
Revision
Date
Sep 2020
Page
12 of 12
a. Switch Not in Auto
b. Low Coolant Level Alarm
c. High Coolant Temperature Alarm
d. Low Oil Pressure Alarm
e. Overcrank Alarm
f. Overspeed Alarm
g. Emergency Stop Activated Alarm
h. Factory Selectable LED
i. Sender Failure Alarm
j. EPS Supplying Load
k. High Coolant Temperature Pre-Alarm
l. Low Coolant Temperature Pre-Alarm
m. Low Oil Pressure Pre-Alarm
n. Low Fuel Level Pre-Alarm
o. Battery Overvoltage Pre-Alarm
p. Weak Battery Pre-Alarm
q. Battery Charger Failure Pre-Alarm
r. Audible Alarm (Horn)
7. Press and release the Alarm Silence pushbutton to end the annunciation sequence.
8. Remove the 10 Hz signal and 24 Vdc control power.
