12 – SYNC (-6V to +6V)
The SYNC input will reset the phases of all oscillators and can be used to
create hard-synced sounds. The SYNC is also good for cleaning up your
transients. The perceived harmonics in FM sound transients are highly
dependent on the current phase of the oscillators.
13 – V/OCT (-5V to +8V)
V/OCT input serves as external control of the oscillator’spitch. It includes
several features to keep you in tune. The main struggle in modular
synthesis is to match your V/OCT source and your oscillator. Pizza has
you covered with the V/OCT CALIBRATION MODE.
