PITCH
PITCH PITCH
CTRL
V/OCT CALIBRATION MODE
AUTOMATIC
CALIBRATION
S TA R T
EXTERNAL
CALIBRATION
0V
&
2V
V/OCT
SOURCE
1
!
A
B
1
2
3
3
45
6
7 7
8
9
10
11
11
12
13 14 15 16
LINEAR FM CV OCTAVE CV
DETUNE CV
EXP FM CV
OCT OSC RATIO CV
OCT OSC EXP FM CV
RATIO OSC RATIO CV
RATIO OSC
BUTTON
SHAPE
BUTTON
OCT OSC
BUTTON
PITCH
BUTTON
RATIO OSC EXP FM CV
OCT OSC WAVE SHAPE CV
MAIN WAVE FOLD CV
MAIN RING MOD CV
OUTPUT VCA
HOLD PITCH & SHAPE
TO ENTER THE V/OCT
CALIBRATION MODE
(ALL LIGHTS COME ON)
HOLD BOTH TO LEAVE
PRESS THE PITCH BUTTON
TO START AUTOMATIC CALIBRATION
1 - CONNECT A CABLE FROM OCT OSC TO V/OCT
2 - WAIT FOR ALL LIGHTS TO GO ON AND
THEN DISCONNECT THE CABLE
PRESS THE OCT OSC BUTTON
TO START EXTERNAL CALIBRATION
1 - Plug a cable from your V/OCT source to the V/OCT input of Pizza.
2 - 0 is blinking = apply 0V (C note in lowest octave) on your V/OCT source.
3 - Press the OCT OSC button to learn what 0V means.
4 - 2 starts blinking = apply 2V on your V/OCT source. (play a note that's two octaves higher =2V)
5 - Press OCT OSC button to learn what 2V means and Pizza will return to V/OCT CALIBRATION MODE.
MAIN
(CARRIER)
OSCILLATOR
WAVE
SHAPE
SHAPE
RING
FOLD
MAIN OUT
PULSE
OCT OSC
OCTAVE
OSCILLATOR
EXT
RATIO
OSCILLATOR
INDEX MOD
FM INDEX
PITCH
DETUNE
V/OCT
SYNC
PHASE MODULATION
MAINxOCT
SOFTHARD
MAINxRATIO
0
SQUARE
PWM by FM INDEX
RATIO: 1/2, 1, 2, 4
ONLY OCTAVES
INTERVALS IN RATIO TOWARDS
THE CARRIER FREQUENCY
SAW
SINE
0
2:1
1:13:19:1 5:1
3:1 4:1 6:1 8:1
