Before connecting the ribbon cable to this module, disconnect your
system from power! Double-check the polarity of the ribbon cable and
that it is not misaligned in any direction. The red wire should match the
-12V rail both on the module and the bus board.
! please make sure of the following
● you have astandard pinout eurorack bus board
● you have +12V and -12V rails on your bus board
● the power rails are not overloaded by current
Although there are protection circuits on this device, we do not accept any
responsibility for damages caused by the wrong power supply connection.
After you’ve connected everything, double-checked it, and closed your
system (so no power lines can be touched by hand), turn on your system
and test the module.
