www.batcafitness.com 15 Fusion 2 Owner’s Manual
Step 5:
Figure 5
Item # Part # Description Qty
15 BFM-10573 Functional Arm Mount 1
16 BFM-10571 User Right Functional Arm 1
17 BFM-10572 User Left Functional Arm 1
36 BFM-10582 Functional Arm Swivel Pulley 2
56 BFH-50146 3/8" Flat Washer (Black) 4
58 BFH-50157 3/8"-16 Nylock (Black) 2
61 BFH-50119 HCS 3/8"-16 1 1/4" P5 2
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
