www.batcafitness.com 17 LD-4 Owner’s Manual
Item # Part # Description Qty
32 BFP-51740 Rear Weight Stack Shroud 1
33 BFP-51711 Placard Plate 1
50 BFP-52373 BHSCS 3/8” x 3/4” 4
49 BFH-50254 HCS 3/8” x 3/4” 2
70 BFH-50146 3/8” Flat Washer 4
Step 12:
DO NOT tighten the four bolts for the Rear Weight Stack Shroud until next step
All Flat Washers and Nylocks are 3/8” unless otherwise noted.
To Next Page
