If the knob is not locked into one of the product selections,
you will not be able to reassemble the 4-Product Selector Valve
- Insert spring into product selector knob
- Align at section of the white disk with the at section of the
product selector knob
Make sure that the machined slot on the white disk is facing
the 5 hole surface
- Align the knob, collar, spring and white disk
(which you just assembled) over the 5 hole section
- Push towards unit and turn counter clockwise 1/8 turn.
- Push hose(s) back toward the center of the 4-Product Selector
Valve until secure
- Using a pliers, pinch hose clamps and
return to area over grey barbs
- Place cover back on unit (22)
Due to the variance of scenarios (water pressure, viscosity of product,
11
gallons of ow per minute, etc.)
