The drawer can be removed and if faulty the drawer fascia can be removed and replaced uncovering the mechanism on
the outside of the drawer side.
Removing Drawer and Fascia
Fascias may require adjustment for correct alignment. This is achieved with the adjusting mechanisms under the interior
covercap.
Adjusting and Fascia
Customer Services
t: 01225 303900
11/16 .V2
Press-in
Drawer adjustment
Remove drawer - use nger triggers on both sides
Remove fascia - turn release mechanism on both sides after removing cams under drawer
