Bathroom Solutions CONTOUR - Door Adjustment Procedures; Hinge Adjustment; Reversible Door Setup

To adjust the door hinges use a screwdriver and follow the appropriate adjustment according to the hinge type:
Customer Services
t: 01225 303900
11/16 .V2
Hinge adjustment
Cloakroom unit reversible door
Door adjustment
- Reattach the door to the
chosen side
- Replace cover caps in the
obsolete hinge holes.
L
R
- Depending on the
intended location of
the unit choose
whether you want a
left or right hand
opening door.
- If the delivered
conguration isn’t
suitable.
- Remove door and
hinges from unit
using a suitable
tool.
1
2
3
1B
C
Door
Furniture Frame
B
A
1
1
2
2
2B
3
3
A B
Door
Furniture Frame
1
1
2
2
1A
2A
To make adjustment 1
(Drawing 1A) tighten/loosen
screw A.
To make adjustment 2
(Drawing 1A) simply turn
screw B.
To make adjustment 1
(Drawing 1B) tighten/loosen
screw A.
To make adjustment 2
(Drawing 1B) simply turn
screw B.
To make adjustment 3
(Drawing 1B) simply turn
screw C
