Battipav srl GB
RECOMMENDED USE
CUTTING TOOL: DIAMOND BLADE WET CUTTING
CONTINUOUS CROWN: ceramic, marble, stone, single-red ceramic
LASER/SECTORS: cement, natural stones, granite, abrasive materials
TURBO: cement, natural stones, granite, refractory.
THE TOOL / MATERIAL TO BE CUT MATCHES ARE PURELY INDICATIVE.
ALWAYS FOLLOW THE INTENDED USE INDICATIONS PROVIDED BY THE CUTTING TOOL MANUFACTURER
BEFORE ANY APPLICATION.
SYMBOLS AND SIGNS:
Danger/prohibition stickers are applied to the machine where necessary. Look at these prior to using the machine.
34
A1 Use of prescribed PPE obligatory (Safety eyewear and earmuffs) B2
A2 Read operating instructions before each use. C1
A3
D1
A4
E1
A5 Do not use discs for wood or metal E2
A6
F1
B1
MANUFACTURER AND MACHINE
The nameplate shown is tted directly on the machine. It indicates all the references and information necessary
for safe operation.
33
A Machine model M IP Level
B Item N Year of manufacture
C Serial number O Max tool diameter
D Power supply voltage P Internal tool diameter
E Power supply frequency Q Accessories
F Current absorption R Accessories
G Installed power rating S Manufacturer’s name
H Tool rotation speed T Manufacturer’s name and address
I Class of protection U Certication Marks
L Starter capacitor
INSTALLATION
TRANSPORT
The PRIME / SUPREME machine can be easily moved by using the transport handles.
Before carrying the machine make sure that:
• the motor carriage is locked by means of the locking knob located on the slide rail;
3
• the legs are in transport position;
• the motor head is locked by means of the locking lever;
• the tube-holder rod is out of its housing.
3
To move the machine, use a four-arm tie rod with the capacity to lift 200 kg or at least 20% more than the
machine weight, by making use of the hooks in the transport handles.
HANDLING
By using the “transport wheels” accessory, the machine can be moved with the aid of a second person.
