Parts List - Washer
Part Description Qty
1 Upper Housing Panel 1
2 Upper Housing 1
3 Lower Housing 1
4 Outlet Wire Strain Plate 2
5 Outlet Strain Plate Grommet 1
6 Power Switch 1
7 Switch Box Cover 1
8 Motor Upper Housing 1
9 Motor & Pump Assembly 1
10 Motor Lower Housing 1
11 Controller Assembly 1
12 Detergent Tank Cap 1
13 Detergent Tank 1
14 Suction Tube 1
15 Wheel Axle 2
16 Wheel 2
17 Wheel Bracket 1
18 Lower Frame 1
19 Frame Rubber foot 1
20 Frame Plate 1
21 15 Degree Spray Nozzle 1
22 25 Degree Spray Nozzle 1
23 40 Degree Spray Nozzle 1
24 Turbo Nozzle 1
25 Detergent Nozzle 1
26 Nozzle Holder 5
27 Upper Panel 1
28 High Pressure Hose 1
Part Description Qty
29 Black Elastic Band 1
30 Clip 1
31 Handle 1
32 Foam Rubber Sleeve 1
33 Wand Mount 1
34 Power Cord 1
35 GFCI Plug 1
36 Power Cord Hanger 1
37 Spring Button 2
38 Cross Recessed Tapping Screw 4
39 Cross Recessed Tapping Screw 8
40 Cross Recessed Tapping Screw 4
41 Cross Recessed Tapping Screw 10
42 Split Pin 2
43 Flat Gasket 2
44 Hex Round Head Screw 6
45 Flat Gasket 7
46 Spring Gasket 7
47 Cap Nut 7
48 Large Gasket 1
49 Hex Round Head Screw 1
50 Spring Gasket 1
51 Flat Gasket 1
52 Hex Round Head Screw 1
53 Hex Round Head Screw 2
54 Flat Head Rivet Nut 2
55 Spray Gun 1
56 Wand 1
To Next Page
