Page 18 For technical questions, please call 1-888-866-5797. Item 70138
SAFETY OPERATION MAINTENANCESETUP
Parts List - Motor
Part Description Qty
A1 Bearing Seat 1
A2 Screw/Spring Gasket/Large Gasket 1
A3 Thrust Ball Bearing 1
A4 Axial Circlip 3
A5 Plunger Cup 3
A6 Plunger 3
A7 Plunger Spring 3
A8 O-Ring 1
A9 Pump Body 1
A10 Hex Cap Screw & Spring Gasket 3
A11 Reciprocating Oil Seal 3
A12 Auxiliary Water Seal Retaining Ring 3
A13 Auxiliary Water Seal 3
A14 O-Ring 3
A15 Middle Sleeve Set 3
A16 Main Water Seal Retaining Ring 3
A17 Main Water Seal 3
A18 Inlet & Outlet Valve Assembly 6
A19 O-Ring 6
A20 O-Ring 1
A21 Inlet & Outlet Valve Cap 1
A22 O-Ring 3
A23 Inlet & Outlet Valve Cap 3
A24 O-Ring 1
A25 Switch Top Rod Nut 1
A26 O-Ring 1
A27 O-Ring 1
A28 Self Tapping Screw 5
A29 Micro Switch Waterproof Cover 1
A30 Micro Switch Left Housing 1
A31 Micro Switch Lead Assembly 1
A32 Micro Switch Right Housing 1
A33 Closed Retaining Ring 1
A34 O-Ring 1
A35 Closed Retaining Ring 1
A36 Rod Spring Seat 1
A37 Rod Spring 1
A38 Switch Top Rod 1
A39 Open Retaining Ring 1
Part Description Qty
A40 O-Ring 1
A41 Hex Set Screw 1
A42 Hex Cap Screw & Spring Gasket 3
A43 Suction Spring 1
A44 Stainless Steel Ball 1
A45 O-Ring 1
A46 O-Ring 1
A47 Suction Connector 1
A48 O-Ring 1
A49 Water Inlet Connector 1
A50 Steel Ball Seat 1
A51 Stainless Steel Ball 1
A52 O-Ring 1
A53 Open Retaining Ring 1
A54 Pressure Regulating Seat 1
A55 Ejector Pin 1
A56 Open Retaining Ring 1
A57 O-Ring 1
A58 Pressure Regulating Valve Stem 1
A59 O-Ring 1
A60 Closed Retaining Ring 1
A61 O-Ring 1
A62 O-Ring 1
A63 Pressure Regulating Valve Body 1
A64 Pressure Regulating Spring 1
A65 Pressure Regulating Nut 1
A66 Nut 1
A67 Pressure Regulating Sheath 1
A68 O-Ring 1
A69 Pressure Retaining Valve Core 1
A70 Pressure Retaining Valve Spring 1
A71 Suction Core 1
A72 O-Ring 1
A73 Suction Body 1
A74 O-Ring 1
A75 O-Ring 1
A76 Water Outlet Connector 1
A77 Pump Head 1
A78 Motor Assembly 1
When ordering replacement parts from this list, the “A” prefix must be included in order to get the correct part.
