Replacing the oven bulb
IMPORTANT: The oven must be disconnected from your
mains supply before you attempt to either remove or
replace the oven bulb.
o Draw out the side guide rails in order
to provide access to the bulb.
o Remove the glass protection cap (C)
from the bulb socket by lifting it with a
screwdriver placed between the cap
and the oven wall.
o Replace the bulb (B) with a 15
W/300°C, screw type pygmy.
o Do not use any other type of bulb.
o Screw the lamp cover back into its original position.
Removing the oven door for cleaning
o The oven door can be removed to give
easier access to the oven when cleaning.
o Open the oven door and move the release
U-shape element forward until it is over
the tooth in the upper sector of the hinge
(see image below).
o Partially close the door, forcing it upwards
at the same time to free the stop tooth
and hinge sector.
o Once the hinge is free, pull the door forwards tilting it slightly
upwards to free the sector.
o To reassemble, proceed in the reverse order, playing attention to
the correct position of the sectors.
24
