Baumatic BR15A - Finalizing Appliance Installation; Securing to Worktop; Levelling and Base Adjustment

17
Adjusting the feet to level your Appliance
Adjust the feet (see picture at
right) until your Fridge sits levelly
on your floor. You can level your
unit using these adjustable feet to
compensate for dips and rises in
your floor surface.
NOTE: You can adjust the height
from 82 to 90 cm. The height
MUST be adjusted before
the
appliance is built into the unit
space designated for it.
DO NOT MOVE THE FRIDGE WHEN THE FEET ARE EXTENDED HIGH!
Drill two holes
and attach your
fridge to the
underside of your
worktop as
shown in figure
at left.
A
d
j
ustin
g
the
base
Place the plinth fascia over
the area indicated with
arrows and push into place
Fastening your Refrigerator to under the Worktop
