Baumatic BR15A - Reversing the Door Swing; Door Reversal Procedure

18
Reversing the swing of the Door
Figure 1 – View of doors Figure 2 - View of doorway
NOTE
: All numbered references apply to both pictures for your
convenience.
1) On the hinge-less side of the fridge’s door, remove the caps (1) that cover
the hinge bracket holes. Keep these in a safe place nearby.
2) Remove the upper hinge (2) using a star-head screwdriver to remove the
screws.
3) Detach and remove the lower hinge (3) by doing the same as you had to
the top hinge.
4) Flip the top hinge and bring it over and down to the bottom corner that is
diagonally opposed to it (4). Screw it in.
5) Flip the bottom hinge and bring it over and up to the top corner that is
diagonally opposed to it (5). Screw it in.
3.
2.
4.
4.
5.
5.
3.
1.
1.
4.
2.
