Baumatic BR22.8A - Door Reversal Procedure

Reversing the door
Caution! After unscrewing any of the fixing
hinges, hold the door to prevent it from falling
and causing damage.
Any parts that you remove from the appliance whilst
reversing the door, should be retained for later use.
We recommend that a minimum of two people carry
out the door reversal process.
1) Top hinge cover (fridge door)
2) Top hinge (fridge door)
3) Bottom hinge (fridge door)
4) Top hinge (freezer door)
5) Washer
6) Bottom hinge (freezer door)
7) Bottom hinge pin (freezer
door)
8) Corner cap (with a hole)
9) Corner cap (without a hole)
