ONCE YOU ARE SURE THAT YOUR OVEN IS NOT DAMAGED (EG. DENTS OR A BROKEN
DOOR) AND THAT THERE ARE NO PACKING MATERIALS AND ACCESSORIES INSIDE IT, YOU
CAN THEN INSTALL IT ON A FLAT SURFACE SUCH AS A COUNTERTOP. BE SURE THAT THE
SURFACE CAN HOLD AT LEAST YOUR MICROWAVE’S WEIGHT (22 kg).
o
BEFORE PLACING ON YOUR COUNTERTOP: REMOVE ANY PROTECTIVE FILM ON THE CABINET
SURFACE.
o BUT DO NOT REMOVE THE LIGHT BROWN MICA COVER THAT IS SCREWED TO THE OVEN CAVITY TO
PROTECT THE MAGNETRON.
o FIND A LEVEL SURFACE THAT PROVIDES ENOUGH OPEN SPACE FOR THE INTAKE AND
OUTLET VENTS.
o
o YOU NEED TO LEAVE A MINIMUM OF 3.0 INCHES (7.5 CM) BETWEEN THE OVEN AND ANY
ADJACENT WALL. ONE SIDE MUST BE LEFT OPEN FOR PROPER AIR FLOW.
o LEAVE A MINIMUM CLEARANCE OF 1¼ INCHES (3.0CM) ABOVE THE OVEN.
o DO NOT REMOVE THE LEGS FROM THE BOTTOM OF THE OVEN.
o DON’T LET ANYTHING BLOCK EITHER THE INTAKE OR THE OUTLET OPENINGS AS THIS
CAN DAMAGE THE OVEN.
o PLACE YOUR MICROWAVE OVEN AS FAR AWAY AS POSSIBLE FROM RADIOS AND TELEVISIONS -
YOUR OVEN MAY CAUSE SIGNAL INTERFERENCE.
o
UNLESS YOU ARE INSTALLING YOUR MICROWAVE IN ACCORDANCE WITH THE
INSTALLATION INSTRUCTIONS ON PAGE 10.
DO NOT PUT YOUR OVEN ON TOP OF
ANY OTHER HEAT-PRODUCING APPLIANCE OR A RANGE COOKTOP
.
DOING SO
COULD DAMAGE YOUR OVEN AND MAKE THE WARRANTY VOID.
Placin
Your Microwave Oven
NOTE:
For in-unit
installation,
please see
next page.
