Removable oven roof liner (P632BS/SS/W only)
Your appliance is supplied with a roof liner, which should be slid over
the top of the grill element.
o Once you have finished cooking, the liner should be removed
and thoroughly cleaned after each use of the appliance.
o Do not allow fat and grease to build up on the oven liner, as this
could cause a fire hazard.
Replacing the oven bulb
IMPORTANT: The oven must be disconnected from
your mains supply before you attempt to either
remove or replace the oven bulb.
o Remove all oven shelves, the enamelled baking
tray and the side rack that is on the same side as
the oven light.
o Remove the light cover by turning it anti-
clockwise.
o Unscrew the bulb clockwise and remove it from
its holder.
o Replace the bulb with a 25 W/300°C, screw type pygmy.
o Do not use any other type of bulb.
o Place the lamp cover back into position.
