o Pans should be lifted on and off the hob surface and not
dragged.
o Cooking zones should not be switched on without cookware
placed on it. Also the cookware should not be empty.
Specifications
PHC620SS
Product dimensions
Height: 510 mm
Width: 580 mm
Depth: 40 mm
Aperture dimensions
Height: 495 mm
Width: 565 mm
Product specifications:
o 1 x 0.75/2.20 kW double hyperspeed zone (diametre 120/210
mm)
o 1 x 1.10/2.00 kW oval hyperspeed zone (diametre 170/265 mm)
o 2 x 1.20 kW hyperspeed zone (diametre 140 mm)
o Front touch control operation
o 4 individual residual heat indicators
o Safety lock
o Timer
o Wrap around designer frame
Standard accessories
o Ceramic hob scraper
Electrical details
Rated Voltage: 230 Vac 50 Hz
Supply Connection: 30 A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 6.6 kW
Mains Supply Lead: 3 core x 6 mm² (not supplied)
