Baur PD-SGS User Manual

Parabolic reflector (optional) PD-SGS
32
/ 46 822-162-1
The parabolic reflector is an ultrasonic sensor for use when detecting partial discharge
activity on exposed insulating surfaces. The reflector increases the sensitivity of the sensor
allowing detection to be effective at up to 25 m. It is commonly used in outdoor switchyards
to detect surface discharge on string and post insulators, sealing ends and other exposed
equipment.
12 P
ARABOLIC REFLECTOR
(
OPTIONAL
)
