Baxi MULTIFIT - Introduction to Outdoor Sensor; Sensor Description; Kit Contents Overview

3
© Baxi Heating UK Ltd 2010
1.1 Description
1. The Outdoor Sensor enables the boiler to respond
effectively to changes in the ambient temperature
outside the dwelling.
2. It must be connected to the boiler PCB as described
in these instructions.
1.2 Contents of Kit
The kit contains:-
Outdoor Sensor Unit (i)
Terminal Strip & Screw (ii)
Replacement Harness (Combi) (iii)
Replacement Harness (System) (iv)
Return Pipe Sensor for System models (v)
Cable Grommet (vi)
1.0 Introduction
(i)
(ii)
(iii)
(iv)
(v)
(vi)
