Assembly Instructions
1. Insert two wood dowels (FF) into the middle holes of the stretcher (E) at both ends.
2. Combine one outer leg (C) and one inner leg (D) together by fitting the cutouts properly.
3. Attach the leg assembly to the stretcher (E) by threading two bolts (BB) with lock washers (CC) and flat
washers (DD) through the countersunk holes on the outer leg (C) and then screw into the threaded inserts on
the stretcher (E). As shown. Tighten the bolts with the enclosed hex wrench.
4.
Rep
eat the same procedure to attach the other two legs (C and D) to the stretcher (E) at the opposite end.
Make sure that the threaded holes on the top of each leg point upward.
5. Insert the wood dowel (FF) into the middle non-threaded hole on the top of each leg (C and D) as a guide.
6.
Position the mounting boards (B) onto the inserted wood dowels (FF) on the legs (C and D).
Insert eight
bolts (AA) with the washers (CC and DD) through the countersunk holes on the mounting boards (B) and
securely screw into the legs (C and D).
As shown.
