BBC Bircher RFGate 2.2.S - Standard Operation and Technical Data; Receiver LED Indicators; Low Battery Voltage Warning; Technical Specifications

4
1234
ON
SELECT
REL21
1 2
4x
Designed in Switzerland / Made in EU
BBC Bircher Smart Access, BBC Bircher AG, Wiesengasse 20, CH-8222 Beringen, www.bircher.com
7 Standard operation
8 Technical data
7.1 Receiver LED indicators
7.2 Warning indicator for low battery voltage
Object
detected
LED off
LED
Receiver: Signal sounds at each activation
Receiver
Supply voltage 12/24 V ACDC
Transmitter memory 10
Output 1 relay 24 V, 1 A; micro switch-off 1B
Power consumption 0.5 W @ 12 V; 1.2 W @ 24 V
Test signal input See page 2, chapter 4.1, I = 3 mA
switching threshold: off = 0.6 V / on = 1.8 V
Transmitter
Battery power 2 x Lithium 3 V Type CR2032
Power consumption Transmitting: 17 mA standby: 16 µA
Safety
OK
LED on
Battery voltage
low
System
Frequency bands 868.95 MHz & 869.85 MHz
Range under optimum conditions up to 100 m
Protection class IEC
60529
IP55
Pollution degree 2
Working temperature -20 °C to +55 °C
Beep
9 EU Declaration of Conformity
11 Contact
See attachment
10 WEEE
Devices with this symbol must be treated separately during disposal. This must be done in accordance with the laws of
the respective countries for environmentally sound disposal, processing and recycling of electrical and electronic equipment.
