8
LIVE APPLICATION: POWERED MIXER
PWR
AMP
IN
PRE
AMP
OUT
MAIN
OUT
TIP/RING/SLEEVE (TRS) INSERT POINT
ON MAIN OR INDIVIDUAL CHANNELS
There are a couple of ways to congure the BBE 482i into a powered mixer. The ideal method
would be into “Pre-Amp Out/Power Amp In” section of the console. If your console does not have
this option, use the main or channel insert points.
