CONTROLS AND CONNECTORS
DC POWER INLET
Accepts any standard
9VDC power supply.
OUTPUT
The output is
designed for run-
ning instrument
cables directly to
your amplifier.
LED
Indicates Sonic
Stomp is engaged.
4
TRUE BYPASS
FOOTSWITCH
Engages the Sonic
Stomp effect.
INPUT
Plug in your guitar,
bass or the previous
instrument level output
of your signal chain.
LOW CONTOUR
CONTROL
Regulates the amount
of phase corrected
bass frequencies.
PROCESS CONTROL
Regulates the amount of
phase correction.
