Page 13
Model No.:VISION
VANTAGE SUB
B60755
item
spare part code
specifications
dosage for unique cabinet
amplifier panel 0300184 capacitor electrolyse 50V 3300uF ± 20% Dia18x35 2
B60756 05153 IC TDA7294 1
091801 knob switch T8019L-TNQ 1
091802 knobswitch T8022L-TNQ 1
0202061 potentiometer rotary A50kx2 L=15mm 1
0202074 potentiometer rotary B20kx2 L=15mm erect 1
othe materials of amplifier discreteness
light panel
6035
diode blue light Dia5 transparency focusing
1
B60536 other materials of light panel discreteness
other spare parts
11565-1
transformer VANTAGE SUB, BT, 220,1
1
power switch KCD5-102 6A/250V
1
other materials
BILL OF MATERIAL
