5
bcstrength.com | bcstrength.co.uk | bcstrength.com.au
ASSEMBLY
INSTRUCTIONS
STEP 3 (cont)
e) Repeat on second hole f) Lightly tighten Bolts on both sides
g) Repeat on the other side
STEP 4
a) Align Wheel Bracket with wheel on the outside
(Part D) onto J-shaped sides (Part C)
b) Hold Back Pad Bracket (Part E) on inside of
J-shaped sides (Part C) and insert Large Bolt
and Large Washer (Part G, Part H)
c) Place Large Washer and Lock Nut (Part H, Part I) d) Repeat on second hole
