BCP SKY4726 - Product Assembly - Part 2; Window Panel Assembly; Window Panel Installation

Slide the part D window panel set together.
If necessary, line the window opening with weather seal (not included). Install the window panel
set horizontally or vertically and lock with a part E plastic stopper.
NOTE: Window panel adjusts from 26.5” to 48”. If window is too small, you may cut the panel to
fit the window (cut on the side opposite of the hole).
PRODUCT ASSEMBLY
3
4
D
HORIZONTAL
VERTICAL
| 7
E
