BCP SKY5969 - Page 14

14 |
PRODUCT ASSEMBLY
12
Attach the part 24 ice dispenser to the part 21 refrigerator door with six part D screws.
11
Insert the hinge peg on the part 20 pantry door into the opening on the part 23 pantry top.
Insert one part N hinge peg into the opening on the part 2 pantry divider, and secure to the
pantry door with two part D screws.
21
24
D
x6
23
2
N
20
D
x2
