BCP SKY5969 - Product Assembly

10 |
18
17
Attach one part I handle to the part 20
pantry door with two part F screws.
Attach one part K door insert and one
part H hinge peg with four part D
screws, two screws each.
Attach one part I handle to the part 21
refrigerator door with two part F screws.
Attach one part K door insert and one
part H hinge peg with four part D
screws, two screws each.
You have completed the pre-assembly.
2
1
Attach the part 13 skirt to the part 12
base with two part A screws.
Attach the part 3 pantry right to the
base with two screws.
BEFORE ASSEMBLY
PRODUCT ASSEMBLY
13
12
A
x2
I
20
H
K
F
x2
D
x4
I
H
K
D
x4
21
F
x2
A
x2
12
3
