BCP SKY5969 - Before Assembly

16
H
I
K
D
x4
F
x2
BEFORE ASSEMBLY
2
1
Insert two part B dowels into the part 5
upper shelf.
Insert four part B dowels into the part 6
shelf divider.
4
3
Attach one part I handle to the part 16
sink cupboard door with two part
F screws.
Attach one part K door insert and one
part H hinge peg with four part D
screws, two screws each.
Insert four part B dowels into the part
8 countertop.
Attach two part M taps and one part L
faucet with three part E screws, one
screw each.
Attach two part Y burners with eight
part F screws.
6 |
B
x2
5
B
x4
6
B
x4
F
x8
E
x3
Y
x2
M
x2
L
8
