BCP SKY5969 - Page 11

| 11
PRODUCT ASSEMBLY
4
3
Locate the part 2 pantry divider and
insert it into the part 3 pantry right.
Attach the part 1 part pantry left with
two part A screws and secure the
divider with four part A screws.
Attach the part 15 sink/oven divider to
the base with one part A screws.
6
5
Attach the part 8 countertop to the part
15 divider with one part A screw.
Secure the countertop to the part 3
pantry right with two part A screws.
Attach the part 15 counter panel to
the countertop.
Attach the part 5 upper shelf to the part
6 shelf divider with one part A screw.
Attach the part 7 lower shelf to the part
6 shelf divider with one part A screw.
1
2
3
A
x6
12
15
A
A
x3
9
8
15
7
6
5
A
x2
