BCP SKY5969 - Page 12

12 |
PRODUCT ASSEMBLY
7
Insert the part 4 pantry back between the pantry sides.
Attach the shelf assembly to the part 3 pantry right and secure with two part A screws.
8
Attach the part 23 pantry top to the pantry sides with four part A screws.
Attach the part 22 oven side and secure with six part A screws.
7
4
5
3
A
x2
A
x10
7
5
8
12
13
3
1
22
23
