BCP SKY5969 - Page 8

8 |
10
9
Insert two part B dowels into the part 9
counter panel.
Attach one part Z2 left holding peg and
one part Z1 right holding peg with four
part D screws, two screws each.
Insert two part B dowels into the part 13 skirt.
12
11
Insert four part B dowels into the part 2
pantry divider.
Insert two part B dowels into the part 22
oven side panel.
Attach two part U handle holders with
two part F screws.
Place the part T oven handle between
the two handle holders.
BEFORE ASSEMBLY
B
x2
Z1
Z2
D
x4
9
13
B
x2
B
x4
2
22
B
x2
F
x2
U
x2
T
