ATTACHING THE BLADE HOLDER
1. Remove the bolt in the lower side of the blade holder
(gure9).
2. Screw the M8 x 20 bolt provided in the upper part of the
bladeholderallthewaydown(gure10).
3. Installthelocknutthatlockstheboltinplace(gure11)
andmountthebladeholderagain(gure12).
4. Adjustthebladeholder(gure13).Seepage6formore
on blade holder adjustment.
It is now possible to attach the cutter bar onto the
ange of the machine.
Figure 10
Figure 11
Figure 12
Figure 13
Assembly Instructions
Figure 9
