B OPERATING INSTRUCTIONS
SPARE PARTS LIST
No
.
Description Size
Piece No.
Description Size
Piece
1 Base frame 1 53 Side rail 87×34.5×1342 1
2 Allen screw M8×50×20 2 54 Wheel Φ62×Φ8.0×t22 1
3 Mother M8 2 55 Damper Φ30×30×M6×6 2
4 Washer Φ8 2 56 Round guide block φ25×φ5×4.5 2
5 Rubber foot Φ50×Φ41×17×M8×27 4 57 Pipe clamp φ16（White） 6
6 Wheel Φ62×Φ8.0×t22 2 58
EVA padding (E21-V1-
12)
t15×30×30 10
7 End cap 40×60×t2.0 2 59 Magnetic ring Φ29×Φ17×t7.5 3
8 Main frame 1 60 Cable clamp 3/8(UC-2) 1
9 Motor mount 1 61 Mains cable clamp SR-5R1 1
10 Hood 1 62 Front support L 1
11 Pipe Φ16×t1.2×23 1 63 Front support R 1
12 Screw M8×75 1 64 Communication cable
SM4PIN/SM4PIN/L-
1200mm/26#
1
13 Screw M8×60 2 65 Tilt angle frame 1
14 Screw M8×15 2 66 Screw M12×Φ14×35×19 2
15 Screw M8×15 1 67 Screw M10×25×15 2
16 Screw M8×45×20 2 68 Plain bearing Φ24×Φ19×Φ14×14×3 2
17 Screw M6×30×Φ16 4 69 Sleeve Φ25×Φ18×t3.0 2
18 Screw M5×10 2 70 Washer Φ14 2
19 Screw M4×10 6 71 Cuff Φ25×Φ17×Φ10×6×1 4
20 Screw ST4×16 4 72 Console holder 1
21 Screw ST4×10 7 73 Overlay 498×175×10.1 1
22 Screw ST3×10 4 74 Screw ST4×16 19
23 Screw ST4×15 2 75 Screw ST4×15 4
24 Handrail frame 1 76 Screw ST4×70 2
25 Spring washer Φ8 3 77 Holder t0.5×490×167 1
26 Spring washer Φ5 17 78 Screw ST4×10 12
27
Serrated lock
washer
Φ5 2 79 Panel 1136EA/571×277×10.8 1
28 Washer Φ8 3 80 Console rear cover 1136EA/571×277×28 1
29 Mother M8 3 81 Console top cover 1
30 Screw M10×35×20 3 82 Lower console cover 1
31 Screw M10×65×20 2 83 Anti-slip pad 1
32 Screw M10 1 84 Speed adjustment
7239EA/SM5PIN/L-
50MM/SPEED+/-
1
33 Washer Φ10 1 85 Hand pulse sensor
7239EA/L-
50MM/SM5PIN/INCLINE
1
34 Washer Φ8 1 86 Communication cable
SM4PIN/SM4PIN/L-
750mm/26#
1
35
Communication
cable
SM5PIN/SM4PIN/L-
750mm/26#/
1 87 Console holder 1
36 Speed sensor L-500 2 88 Cables 3330EA/L-1000mm 1
