B OPERATING INSTRUCTIONS
37 Controller AC220V 1 89 Security key J52×15×15（/L-700 1
38 Cables L-300mm/1.5mm2 1 90 Plug J86×20×16 1
39 Cables L-300mm/1.5mm2 1 91 Acrylic glass pane t1.0×554×260 1
40 Rocker switch KCD4 1 92 D-shaped pipe plug DX40×80 2
41 Switches
10A/ABR21-
16/250VAC
1 93 ezfit connection Φ29×t1.2×340 1
42 Cables L-100mm/1.5mm2 1 94 Screw M8×50×20 1
43 Plug 3×1.0mm2×2000 1 95 Screw M8×30×20 1
44 Front idler pulley Φ88×Φ50×Φ17×606 1 96 Double round tube plug Φ33×Φ23×48 1
45
Φ50×Φ17×529×578 1 97 Mother M8 2
46 Motor
1.5HP/DC180V/4600R
PM/Φ32/36
1 98 Washer Φ88×Φ50×Φ17×606 2
47 Tilt motor
1/18HP/75mm/AC220V
(195mm)
1 99 Gas spring
720×318×Φ10×Φ8.2×35
0N
1
48 Running deck 1300×604×t18 1 100 Pipe t0.6×16.5×43 1
49 Running mat 2930×500×t1.6 1 101 Screw M8×50×20 4
50 Strap
174（442）PJ6
1 102 Screw M8×15 8
51 Motor cover 367.5×673×36.7 1 103 Screw M6×10 4
52 Rear cover 673×93×51 1 104 Keypad cover t1.5×573×19 1
