1. INSTALLING THE BASE
To install the ONE child restraint system, follow the
steps below:
1a. Attach the anti-swivel system (3) it will click into
place
1b. Unfold the leg (13) until it is in the vertical position
as shown.
1c. Move the button (15) to slide the ISOFIX (14) bac-
kwards until the connector is completely unfolded. Do
the same operation for both connectors.
1d. Guide the connectors towards the ISOFIX anchors in
your vehicle until they click into place and the indicator
changes from red to green on both sides of the base.
1e. Push the seat backwards pressing it against the
backrest of the vehicle seat. Then try to pull the seat
towards you to make sure that it is correctly secured in
place.. INSTALACIÓN DE LA BASE
1f. Press the button (12) to adjust the height of the
support leg (13) to ensure that it is touching the oor.
It should not be placed on top of any type of compart-
ment. At this point make sure that the position of the
support leg is at an angle of 90o from the seat base.
The visual ISOFIX indicators will show whether the con-
nector is closed or open. It may be that the connector
is closed without being secured in the ISOFIX anchor.
Please check this by pulling the seat once the connec-
tors are correctly locked into the vehicle anchors.
To remove the seat, follow the same steps in reverse
order:
1g. Move the button (10) to open the connector and
release the anchors.
2. INSTALLING THE SEAT ON THE BASE
To attach the safety seat to the base, follow the steps
below:
2a. Let the baby carrier drop gently into place on the
base.
2b. Check that both sides are locked into place; the
baby carrier is correctly secured when you hear it click
into place and the part on the base of the baby carrier
IM 2041,02 ONE instruc ok.indd 25 3/5/21 14:10
