6
Capacity scales
in liter
Capacity
scales
in gallons
Water Inlet
with filter net
inside
Positions for
extension
nozzle
Position
for nozzle
Gun hook
HOOKS FOR SPRAYER GUN AND NOZZLES
ATTENTION: Pesticide or liquid fertilizer must be dissolved completely before pouring
into the tank in case that any solid material will block off the spraying.
Remove any solids on the filter after injection.
INTRODUCTION AND INSTALLATION
HOW TO USE THE WATER TANK
Rotate the lid of the water inlet as the photo shown below.
Pour the water, pesticide or liquid fertilizer, then tighten the lid.
Air valve
Outlet hole
