Read this operator’s manual and safety
rules before operating your generator.
generator components
1. Control Panel
2. Fuel Tank
3. Fuel Gauge
4. Oil Drain Plug
5. Recoil Starter
6. Tank Cap
7. Frame
8. Air Cleaner
9. Battery
10. ON/OFF Switch
11. Auto throttle
1.
17.
18.
19.
19.
15.
16.
9.
22.
5.
10.
20.
8.
4.
11.
12.
13.
21.
14.
2.6.7. 3.
12. DC Connection
13. DC Breaker
14. Voltmeter
15. 120V 3 Prong Twistlock
16. 240V 4 Prong Twistlock
17. Ground
18. 120V GFCI
19. AC Breaker
20. Wheel Kit
21. Oil Dipstick
22. Handles
