9.2 Generator won’t produce power
· Safety device (DC protector) to “OFF”…. Press the DC protector to
“ON”.
· The AC pilot light (Green) goes off …. Stop the engine, then restart.
10. SPECIFICATIONS
Item I2000L Generator
Generator
Type Silent Inverter
Rated frequency (Hz) 60
Rated voltage (v) 120
Rated output power (kW) 1.6
Max output power (kW) 2
Power Factor 1
Charging Voltage (DC)(V) 12
Charging Current (DC)(A) 8.3
Overload Protect (DC) Non-fuse Protector
Phase Single
Engine
Engine R80-i MZ80-20i
Engine type Single cylinder, 4-stroke, forced
air cooling, OHV
Displacement (cc) 79.7 79
Fuel type Unleaded Gasoline
Fuel tank capacity (L) 4
Fuel Consumption (g/
(kW·h)
450
Continue Running Time (at
rated power)(h)
4
Oil Capacity (L) 0.35
Spark Model No. TORCH-A5RTC E6TC-E6RTC
Starting mode Recoil Starter
Generator
set
Length x Width x Height
(mm)
498 x 290 x 459
Net weight (kg) 22
11. WIRING DIAGRAM
SPECIFICATIONS WIRING DIAGRAM
