NO. CODE Description NO. CODE Description
1 511120 O-RING 2.5X1.8 27 421510 COVER
2 511100 O-RING 12.2X1.75 28 322660 BACK COVER
3 511060 O-RING 15.5X1.75 29 410620 BUMPER
4 511110 O-RING 16.4X1.8 30 110440 BODY
5 511080 O-RING 16X1.25 31 322720 SILENCER
6 511090 O-RING 8X2.6 32 322780 CAP
7 511050 O-RING 27.5X2.6 33 410660 DAMPER
8 511040 O-RING 31.5X2.65 34 310750 CYLINDER
9 510390 O-RING 17X2.65 35 640320 ROLL PIN 4X29
10 322830 PIN 36 421450 VALVE GASKET
11 640290 ROLL PIN 3X24 37 421460 VALVE CAP
12 640310 ROLL PIN 4X19.5 38 421470 TRIGGER
13 630300 WASHER 39 310450 VALVE CYLINDER
14 610490 BOLT M4X12 40 421440 VALVE SHAFT
15 610500 BOLT M4X16 41 410640 INTERMEDIATE VALVE
16 610720 BOLT M4X14 42 322790 BACK NOSE ASSEMBLY
17 310470 END CAP 43 310500 COVER
18 621030 TENSION SPRING 44 210850 FRONT NOSE
19 511130 O-RING 19.5X3 45 322800 DRIVER BLADE
20 322770 FEEDER BAR 46 322750 PULLEY
21 421430 PISTON 47 322960 PIN
22 421480 VALVE PIN 48 421490 STOP
23 421500 END PIECE 49 640170 ROLL PIN 3X28
24 421520 COVER 50 410630 RUBBER HANDLE
25 621040 LEG SPRING
26 322700 LOCKING PAWL P1. D322801 DRIVER UNIT
